WH636-25-107V
Dimensions: (Inches)
| O.D. | I.D. Bottom | O.A.L |
|---|---|---|
| 5.97 | 3.905 | 35.88 |
Construction:
Water Absorbent Shut Off, Viton, By-Pass
Beta Rating:
Beta 25[c] >= 1000 (ISO 16889 & DFE)
Gasket Material:
Viton
End Cap:
Corrosion Resistant CS/AL
Adhesive:
Epoxy
By-Pass:
YES, 45 psid
Media Type:
Microglass supported both sides
Gasket Type:
O-Ring
Inner Core:
NONE
Flow Direction:
OUT to IN
Operating Limits:
- Recommended Change Out: 25 PSID
- Maximum Temperature: 250 °F
- Collapse Rating: 150 PSID
