HY204-10W-53HE
Dimensions: (Inches)
| O.D. | I.D. Bottom | O.A.L |
|---|---|---|
| 1.735 | 1.025 | 4.5 |
Construction:
EPDM O-Ring, SOE, 3000 psid
Nominal Efficiency:
10 Micron
Gasket Material:
EPDM
End Cap:
Corrosion Resistant CS/AL
Adhesive:
Epoxy
By-Pass:
NONE
Media Type:
Stailess Steel Wire Mesh
Gasket Type:
O-Ring
Inner Core:
Plated CS
Flow Direction:
OUT to IN
Operating Limits:
- Recommended Change Out: 25 PSID
- Maximum Temperature: 250 °F
- Collapse Rating: 3000 PSID
